PORTABLES
The marsh rustles in the fall breeze as you deploy your decoys. There’s nothing like a trusty Yamaha Portable outboard for a crisp day of fishing or duck hunting. Yamaha’s Portable F25, F20 and F15 pack impressive power-to-weights and all the advantages of Yamaha’s award-winning, portable design, including carrying handles, incredibly light weights and more. The F25 even comes in matte brown, in case stealthy is part of the ask. No matter what’s ahead, your Yamaha Portable will be ready to go.
Meet the Lineup
25 HP
Our 432-cc 25-hp portable outboard features a streamlined, portable design and class-leading power-to-weight. While it’s 25 percent lighter than its previous design, it still packs exciting features like battery-less EFI. Pull-start models can now take advantage of this feature, plus the system is designed with an automatic decompression device to require even less effort for manual starting.
- Now available in new pearlescent white and matte brown*, in addition to Yamaha gray
- Only 126 pounds (15” shaft model)
- Available in 15” and 20” shaft lengths and in a High-Thrust design (T25)
- Powerful 16-amp alternator
- Variable Trolling RPM Switch (VTS®) accessible depending on rigging
- Select models, including 15-inch shafts, feature a shorter tiller with Power Trim & Tilt and a tilt-up feature for ease in small spaces
*New color options available in select models and subject to availability.
20 HP
Our 362-cc 20-hp portable outboard is built on the same award-winning platform as the F25. Its SOHC in-line design and streamlined intake manifold delivers solid power. Not only that, but it’s one of the most fuel efficient in its class. At just 126 pounds, it’s suitable for lightweight craft such as aluminum fishing boats, tenders and inflatables.
- Only 126 pounds (15” shaft model)
- Available in 15” and 20” shaft lengths
- Powerful 16-amp alternator
15 HP
Our 362-cc 15-hp portable features a SOHC in-line, two-cylinder design. Its single carburetor and CDI Microcomputer Ignition System make it one of the most fuel efficient in its class. At just 111 pounds, it’s suitable for lightweight craft such as aluminum fishing boats, tenders and inflatables.
- Only 111 pounds (15” shaft model)
- Available in 15” and 20” shaft lengths
- Powerful 10-amp alternator
25 HP
Engine Comparison
| Weight † | 57kg (126 lbs) - 65kg (143 lbs) |
|---|---|
| Full Throttle RPM Range | 5000 - 6000 |
| Fuel Induction System | EFI |
| Recommended Engine Oil | Yamalube® 4M (See owner's manual) |
| Engine Type | 2 cyl |
| Displacement | 432cc |
| Bore x Stroke | 65 x 65.1mm / (2.56 x 2.56 in) |
| Prop Shaft Horsepower | 25 hp at 5500 rpm |
| Alternator Output at W.O.T. | 16 amp |
| Compression Ratio | 9.3:1 |
| Recommended Fuel | Octane 87 |
| Recommended Fuel Filtration | Yamaha 10-Micron Fuel/Water Separating Filter (external) |
| C.A.R.B. Rating | 2-Star |
| Exhaust | Through Propeller |
| Intake | 4 |
| Ignition | CDI Microcomputer |
| Spark Plug | DPR6EB-9 |
| Starting System | Electric & Manual |
| Lubrication | Wet Sump |
| Engine Oil Capacity | 1.1L/1.0L |
| Recommended Cooling | Thermostatic Control |
| Ethanol Blend Limit | 10% Maximum |
| Gear Ratio | 2.00:1 |
| Gear Shift | Forward, Neutral, Reverse |
| Shaft Length | 15" - 20" |
| Degree of Tilt | 62° - 63° |
| Degree of Trim | -3° through +16° |
| Mounting Centers | N/A |
| Steering | Tiller |
| Steering Angle (maximum) | 45° from center, either direction |
| Warranty | Limited 3-year Pleasure, 3-year Government, 1-Year Commercial |
† Weight refers to shortest shaft length, and is measured without motor oil, gearcase oil and propeller (except models 25 hp and under, which include a standard propeller). All Jet model weights include the jet pump assembly (weight estimated).
20 HP
Engine Comparison
| Weight † | 57 kg (126 lbs) - 66 kg (146 lbs) |
|---|---|
| Full Throttle RPM Range | 5000 ~ 6000 rpm |
| Fuel Induction System | EFI |
| Recommended Engine Oil | Yamalube® 4M (See owner's manual) |
| Engine Type | 2 cyl |
| Displacement | 362 cc |
| Bore x Stroke | 65 x 65.1mm (2.554 x 2.558 in) |
| Prop Shaft Horsepower | 20 hp @ 5500 rpm |
| Alternator Output at W.O.T. | 16 Amp |
| Compression Ratio | 9.3:1 |
| Recommended Fuel | Octane 87 |
| Recommended Fuel Filtration | Yamaha 10-Micron Fuel/Water Separating Filter (external) |
| C.A.R.B. Rating | 2-Star |
| Exhaust | Through Propeller |
| Intake | 4 |
| Ignition | CDI |
| Spark Plug | DPR6EB-9 |
| Starting System | Electric & Manual |
| Lubrication | Wet Sump |
| Engine Oil Capacity | 1.1L/1.0L |
| Recommended Cooling | Thermostatic Control |
| Ethanol Blend Limit | 10% Maximum |
| Gear Ratio | 2.00:1 |
| Gear Shift | Forward, Neutral, Reverse |
| Shaft Length | 15" - 20" |
| Degree of Tilt | 62°- 63° |
| Degree of Trim | -3° through +16° |
| Mounting Centers | N/A |
| Steering | Tiller |
| Steering Angle (maximum) | 45° from center, either direction |
| Warranty | Limited 3-Year Pleasure, 3-Year Government, 1-Year Commercial |
† Weight refers to shortest shaft length, and is measured without motor oil, gearcase oil and propeller (except models 25 hp and under, which include a standard propeller). All Jet model weights include the jet pump assembly (weight estimated).
15 HP
Engine Comparison
| Weight † | 50kg (111 lbs) - 59kg (132 lbs) |
|---|---|
| Full Throttle RPM Range | 5000 ~ 6000 rpm |
| Fuel Induction System | Carb |
| Recommended Engine Oil | Yamalube® 4M (See owner's manual) |
| Engine Type | 2 cyl |
| Displacement | 362 cc |
| Bore x Stroke | 63 x 58.1mm (2.48 x 2.29 in) |
| Prop Shaft Horsepower | 15 hp @ 5500 rpm |
| Alternator Output at W.O.T. | 10 Amp |
| Compression Ratio | 9.3:1 |
| Recommended Fuel | Octane 87 |
| Recommended Fuel Filtration | Yamaha 10-Micron Fuel/Water Separating Filter (external) |
| C.A.R.B. Rating | 3-Star |
| Exhaust | Through Propeller |
| Intake | 4 |
| Ignition | CDI |
| Spark Plug | DPR6EB-9 |
| Starting System | Electric & Manual |
| Lubrication | Wet Sump |
| Engine Oil Capacity | 1.8L/1.6L |
| Recommended Cooling | Thermostatic Control |
| Ethanol Blend Limit | 10% Maximum |
| Gear Ratio | 2.08:1 |
| Gear Shift | Forward, Neutral, Reverse |
| Shaft Length | 15" - 20" |
| Degree of Tilt | 67°- 71° |
| Degree of Trim | -4° through +16° |
| Mounting Centers | N/A |
| Steering | Tiller |
| Steering Angle (maximum) | 45° from center, either direction |
| Warranty | Limited 3-Year Pleasure, 3-Year Government, 1-Year Commercial |
† Weight refers to shortest shaft length, and is measured without motor oil, gearcase oil and propeller (except models 25 hp and under, which include a standard propeller). All Jet model weights include the jet pump assembly (weight estimated).
25 HP
Compatible Controls
Compatible Gauges
Prop Selector
Enter your details. Find the right prop. Easily zero-in on the best propeller options based on your type of craft, horsepower and performance goals with this smart, online tool.
visit yamaha prop selector
20 HP
Compatible Controls
Compatible Gauges
Prop Selector
Enter your details. Find the right prop. Easily zero-in on the best propeller options based on your type of craft, horsepower and performance goals with this smart, online tool.
visit yamaha prop selector
15 HP
Compatible Controls
Compatible Gauges
Prop Selector
Enter your details. Find the right prop. Easily zero-in on the best propeller options based on your type of craft, horsepower and performance goals with this smart, online tool.
visit yamaha prop selector
| Boat Model: Engine: Bulletin: |
Alumacraft Escape 145 CS F25LA View |
|---|---|
| Boat Model: Engine: Bulletin: |
Alumacraft Escape 145 Tiller F25LA View |
| Boat Model: Engine: Bulletin: |
Outcast® 16 V F25LA View |
| Boat Model: Engine: Bulletin: |
Polar Kraft® Outlander V 156 SC® F25LA View |
| Boat Model: Engine: Bulletin: |
Polar Kraft® Sportsman MV 1585 SE® F25LA View |
| Boat Model: Engine: Bulletin: |
Starcraft® 16 Patriot F25LC View |
| Boat Model: Engine: Bulletin: |
Zodiac® 340 BayRunner F25LA View |
| Boat Model: Engine: Bulletin: |
Zodiac® 310 BayRunner F20LPA View |
|---|
-
WHITE
-
GRAY
-
BROWN
-
GRAY
-
GRAY
Gallery
THE OUTSTANDING,
25 HP PORTABLE
Yamaha’s F25 is still the lightest 25-horsepower outboard on the water—two stroke or four stroke. Its portable design and class-leading power-to-weight mean 25 horses can boldly go where they’ve never gone before. Jons. 14-foot aluminum fishing boats. The bed of your truck.
Features & Benefits
The F25, F20 and F15 all feature a two-valve-per-cylinder, single-overhead-camshaft design that provides better breathing and more power.
An optimally balanced crankshaft and labyrinth exhaust deliver smooth power, while Microcomputer Ignition adjusts timing to maintain maximum engine performance, economy and power under all conditions.
An intake silencer and manifold on the F20 and F15 result in more direct airflow, for minimum noise and maximum power.
An acceleration pump on the F20 and F15 gives the engine the fuel it needs--when it needs it--like during rapid throttle advance. This ensures responsive acceleration
A 45-degree steering angle in each direction means great maneuvering potential.
A Freshwater Flush Device allows you to flush the engine without running it, for added convenience and extended engine life.
Incredible light weights, built-in resting pads and carry handles, an easy oil retention system and an optional folding tiller handle, allow for easy carrying and on-side storage without oil leakage or cowling scuffs.
